Field software that works like you do.

Create residential electrical load calculations and download professional PDF reports.

TAPEMEN Load Calculator — residential service load

PROJECT

Job information

These details appear in the PDF header.

Which method is permitted (NEC 2023 / CEC 2025)
  • Standard — NEC 220 Part III (220.40). Permitted for any dwelling service or feeder, any size. Required where 220.82 / 220.83 are not permitted: a sub-panel that feeds only part of a dwelling (any size), or a feeder under 100 A.
  • Optional — NEC 220.82. Only where the total connected load of a dwelling unit is served by one 120/240 V or 208Y/120 V three-wire service or feeder with an ampacity of 100 A or more (220.82(A)). An ADU feeder qualifies at 100 A or more; a sub-panel feeding part of a house does not.
  • Existing dwelling — NEC 220.83. Checks whether the existing service or feeder of a whole existing dwelling unit (120/240 V or 208Y/120 V, three-wire) can take added loads — 220.83(A) without new A/C or space heat, 220.83(B) with it.
  • Sub-panel feeder — NEC 215.2(A)(1) and 215.3. Feeder conductors (215.2(A)(1)) and the feeder breaker (215.3) must be rated for at least the calculated load of the panel they supply; only the loads fed from that panel are entered. Code basis: 2025 CEC, based on the 2023 NEC.

Enter amps or VA from the equipment label. First 10,000 VA at 100%, remainder at 40%; HVAC and EV per their own rules. The general residential method.

CALCULATION SCOPESelect why this calculation is being prepared. The choice controls service-rating fields, results and PDF wording.
Start typing the property address, then choose the correct Google suggestion to fill street, city, state and ZIP. Checking access to automatic property details…
PROPERTY RECORD DATAImported values stay editable. Square footage is also copied to the dwelling load section.
Existing service checkThe calculated load is compared with the existing main breaker; the minimum standard size is shown in the result.
SERVICE EQUIPMENT AND POWER SOURCESRecorded in the PDF. Solar and battery data do not reduce the dwelling load calculation.
Next: dwelling area, small-appliance circuits and fixed appliances.
